CR310 Datalogger with Ethernet
Compact Data Logger with Ethernet
Ideal for small applications
weather applications water applications energy applications gas flux and turbulence applications infrastructure applications soil applications

Overview

The CR310 is a multi-purpose, compact, low-cost measurement and control data logger that includes an integrated 10/100 Ethernet port and removable terminal connectors. This entry-level data logger, with its rich instruction set, can measure most hydrological, meteorological, environmental, and industrial sensors. It will concentrate data, making it available over varied networks and deliver it using your preferred protocol. The CR310 also performs automated on-site or remote decision making for control and M2M communications. The CR310 is ideal for small applications requiring long-term, remote monitoring and control.

The primary differences between the CR300 and CR310 are that the CR310 offers removable connectors and a 10/100 Ethernet connection.

The CR310 has multiple radio options that are suitable for different regions:

  • CR310-RF407: US and Canada
  • CR310-RF412: Australia and New Zealand
  • CR310-RF422: Europe
  • CR310-RF427: Brazil

Note: Campbell Scientific does not recommend the CR310 for use as a PakBus router in networks with more than 50 devices. Large arrays or string variables may also reach memory limits. For such applications, a CR1000X Measurement and Control Datalogger is recommended.

Read More

Benefits and Features

  • Set up easily with PC software and USB connectivity
  • Measure with confidence analog and digital sensors
  • Internet ready–email, FTP, HTTP/web, TCP–with required add-ons
  • Trust in the Campbell Scientific quality, including integral surge and ESD protection
  • Network wirelessly to another node or Internet gateway with integrated radio option
  • Wiring made easy through removable terminal block
  • Communicate from anywhere when using cellular or satellite peripheral
  • Measure smart sensors using RS-232 or SDI-12
  • Connect with PakBus, Modbus, DNP3, GOES, and other standard communication protocols
  • Analyze and control with programmability and multiple general purpose I/O
  • Notify with event-driven communications and physical outputs

Images

CR310 back view
CR310 left view (no radio)
CR310 (with radio) left view
CR310 right view (no radio)
CR310 (with radio) right view
CR310 top view (no radio)
CR310 (with radio) top view
CR310 bottom view (no radio)
CR310 (with radio) bottom view
CR310-RF407 glam view
CR310-RF407 front view
CR310-RF412 front view
CR310-RF422 glam view
CR310-RF422 front view
CR310-WIFI glam view
CR310-WIFI front view
CR310-WIFI with attached antenna
CR310-CELL200 front tilt view
CR310-CELL200 front view
CR310-CELL200 front tilt view
CR310-CELL200 with Ships With items
CR310-CELL205 front tilt view
CR310-CELL205 front view
CR310-CELL205 front tilt view
CR310-CELL210 front tilt view
CR310-CELL210 front view
CR310-CELL210 front tilt view

Detailed Description

Terminal Descriptions

  • One switched 12 V terminal (SW12V) for powering sensors or communication devices, 1100 mA @ 20°C
  • Two sensor excitation or continuous 0.15 to 5 V terminals (VX1, VX2) for sensor excitation or output control
  • Six multipurpose analog input terminals (SE1 - SE6)
    • Analog functions (SE1 - SE6)
      • Analog inputs: 6 single-ended or 3 differential inputs with -100 to +2500 mV and ±34 mV ranges 24 bit ADC
      • 4 to 20 mA or 0 to 20 mA inputs (SE1, SE2 only)
    • Digital I/O functions (SE1 - SE4) consist of 3.3 V logic levels for:
      • High frequency counter (35 kHz)
      • Pulse width modulation
      • Interrupts and timer input
      • Period average (200 kHz, amplitude dependent)
  • Two Pulse Counting Terminals (P_SW, P_LL)
    • P_SW
      • Switch closure (150 Hz)
      • High frequency counter (35 kHz)
    • P_LL
      • Low level ac (20 kHz)
      • High frequency counter (20 kHz)
  • Two Control Terminals (C1, C2): C terminals are software configurable for digital functions
    • Digital I/O functions consist of 5 V output and 3.3 V input logic levels for:
      • SDI-12
      • High frequency counter (3 kHz)
      • Switch closure (150 Hz)
      • General status/control
      • Voltage source 5 V: 10 mA @ 3.5 V
      • Interrupts
      • Serial asynchronous communication Tx/Rx pair

Specifications

-NOTE- Additional specifications are listed in the CR300-Series Specifications Sheet.
Operating Temperature Range
  • -40° to +70°C (standard)
  • Non-condensing environment
Maximum Scan Rate 10 Hz
Case Material Powder-coated aluminum
Analog Inputs 6 single-ended or 3 differential (individually configured)
Pulse Counters 8 (P_SW, P_LL, C1, C2, and SE1 to SE4)
Voltage Excitation Terminals 2 (VX1, VX2)
Communications Ports
  • USB Micro B
  • RS-232
  • 10/100 Ethernet RJ45
Switched 12 Volt 1 terminal
Digital I/O 7 terminals (C1, C2, P_SW, and SE1 to SE4) configurable for digital input and output. Includes status high/low, pulse width modulation, external interrupt, and communication functions. Exception: The SE4 terminal doesn't do external interrupt.
Input Limits -100 to +2500 mV
Analog Voltage Accuracy
  • Accuracy specifications do not include sensor or measurement noise.
  • ±(0.04% of measurement + offset) at 0° to 40°C
  • ±(0.1% of measurement + offset) at -40° to +70°C
ADC 24-bit
Power Requirements 16 to 32 Vdc for charger input (CHG) (Current limited to 0.9 A maximum for power converter or solar panel input.)
Power Requirements 10 to 18 Vdc for external batteries (BAT)
Real-Time Clock Accuracy ±1 min. per month
Internet Protocols Ethernet, PPP, RNDIS, ICMP/Ping, Auto-IP(APIPA), IPv4, IPv6, UDP, TCP, TLS (v1.2), DNS, DHCP, SLAAC, NTP, Telnet, HTTP(S), FTP(S), SMTP/TLS, POP3/TLS
Communication Protocols PakBus, Modbus, DNP3, SDI-12, TCP, UDP, and others
CPU Drive/Programs 80 MB serial flash
Data Storage 30 MB serial flash
Idle Current Drain, Average 10 mA (@ 12 Vdc with Ethernet link idle)
Active Current Drain, Average 56 mA (@ 12 Vdc with Ethernet link active, processor always on)
Dimensions 16.26 x 7.62 x 5.68 cm (6.4 x 3.0 x 2.2 in.)
Weight 288 to 306 g (0.64 to 0.68 lb) depending on communication option selected

CR310-RF407 Option
Radio Type Frequency Hopping Spread Spectrum (FHSS)
Output Power 5 to 250 mW (user-selectable)
Frequency 902 to 928 MHz (US, Canada)
RF Data Rate 200 kbps
Receive Sensitivity -101 dBm
Antenna Connector RPSMA (external antenna required; see www.campbellsci.com/order/rf407 for Campbell Scientific antennas)
Idle Current Drain, Average 12 mA (@ 12 Vdc)
Active Current Drain, Average < 80 mA (@ 12 Vdc)

CR310-RF412 Option
Radio Type Frequency Hopping Spread Spectrum (FHSS)
Output Power 5 to 250 mW (user-selectable)
Frequency 915 to 928 MHz (Australia, New Zealand)
RF Data Rate 200 kbps
Receive Sensitivity -101 dBm
Antenna Connector RPSMA (external antenna required; see www.campbellsci.com/order/rf412 for Campbell Scientific antennas)
Idle Current Drain, Average 12 mA (@ 12 Vdc)
Active Current Drain, Average < 80 mA (@ 12 Vdc)

CR310-RF422 Option
Radio Type 868 MHz SRD 860 with Listen Before Talk (LBT) and Automatic Frequency Agility (AFA)
Output Power 2 to 25 mW (user-selectable)
Frequency 863 to 870 MHz (European Union)
RF Data Rate 10 kbps
Receive Sensitivity -106 dBm
Antenna Connector (External antenna required; see www.campbellsci.com/order/rf422 for Campbell Scientific antennas.)
Idle Current Drain, Average 9.5 mA
Active Current Drain, Average 20 mA

CR310-RF427 Option
Radio Type Frequency Hopping Spread Spectrum (FHSS)
Output Power 5 to 250 mW (user-selectable)
Frequency 902 to 907.5 MHz/915 to 928 MHz (Brazil)
RF Data Rate 200 kbps
Receive Sensitivity -101 dBm
Antenna Connector RPSMA (External antenna required.)
Idle Current Drain, Average 12 mA (@ 12 Vdc)
Active Current Drain, Average < 80 mA (@ 12 Vdc)

CR310-WIFI Option
Operational Modes Client or Access Point
Operating Frequency 2.4 GHz, 20 MHz bandwidth
Antenna Connector Reverse Polarity SMA (RPSMA)
Antenna pn 16005 unity gain (0 dBd), 1/2 wave whip, omnidirectional with articulating knuckle joint for vertical or horizontal orientation
Transmit Power 7 to 18 dBm (5 to 63 mW)

CR310-CELL205 Option
-NOTE- The CR310-CELL205 option is not compatible with a Verizon cellular network.
Cell Technologies
  • 3G (UMTS/HSPA+)
  • 4G (LTE CAT-1)
3G Frequency Bands 850, 1700/2100 (AWS), and 1900
4G Frequency Bands 700, 850, 1700/2100 (AWS-1), 1900
Antenna Connector SMA (External antenna required; see www.campbellsci.com/order/cr310 for Campbell Scientific antennas.)
SIM Interface 3FF (6 position/contacts)
Supports SIMs that require 1.8 or 3 V.

CR310-CELL210 Option
-NOTE- The CR310-CELL210 option is only compatible with a Verizon cellular network. CR310-CELL205 Option No
Cell Technologies 4G (LTE CAT-1)
4G Frequency Bands 700, 850, 1700, 1900, 2100
Antenna Connector SMA (External antenna required; see www.campbellsci.com/order/cr310 for Campbell Scientific antennas.)
SIM Interface 3FF (6 position/contacts)
Supports SIMs that require 1.8 or 3 V.

CR310-CELL215 Option
-NOTE- The CR310-CELL215 option is intended for use in EMEA countries.
Cell Technologies
  • 2G (GSM/GPRS/EDGE)
  • 3G (UMTS/HSPA+)
  • 4G (LTE CAT-1)
2G Frequency Bands 900 and 1800 MHz
3G Frequency Bands 850, 900, and 2100 MHz
4G Frequency Bands 800, 850, 900, 1800, 2100, and 2600 MHz
Antenna Connector SMA (External antenna required; see www.campbellsci.com/order/cr310 for Campbell Scientific antennas.)
SIM Interface 3FF (6 position/contacts)
Supports SIMs that require 1.8 or 3 V.

CR310-CELL220 Option
-NOTE- The CR310-CELL220 option is intended for use in Australia and New Zealand.
Cell Technologies
  • 3G (UMTS/HSPA+)
  • 4G (LTE CAT-1)
3G Frequency Bands
  • 850 and 2100 MHz (EC-21AUT)
  • 850, 900, 1900, and 2100 MHz (EC-21AU)
4G Frequency Bands
  • 700, 850, 1800, 2100, and 2600 MHz (EC-21AUT)
  • 700, 900, 1700, 1800, 1900, 2100, and 2600 MHz (EC-21AU)
Antenna Connector SMA (External antenna required; see www.campbellsci.com/order/cr310 for Campbell Scientific antennas.)
SIM Interface 3FF (6 position/contacts)
Supports SIMs that require 1.8 or 3 V.

CR310-CELL225 Option
-NOTE- The CR310-CELL225 option is intended for use in Japan.
Cell Technologies 4G (LTE CAT-1)
4G Frequency Bands 800 (lower), 800 (upper), 850+, 900, 1800, and 2100 MHz
Antenna Connector SMA (External antenna required; see www.campbellsci.com/order/cr310 for Campbell Scientific antennas.)
SIM Interface 3FF (6 position/contacts)
Supports SIMs that require 1.8 or 3 V.

Compatibility

Note: The following shows notable compatibility information. It is not a comprehensive list of all compatible or incompatible products.

Software

Product Compatible Note
DevConfig Version 2.12 or higher
LoggerLink Version 1.5 or higher
LoggerNet Version 4.4 or higher
LoggerNet Mobile Connect Version 1.1 or higher
PC200W (retired) Version 4.4 or higher
PC400 Version 4.4 or higher
RTDAQ
Short Cut Version 3.2 or higher

Additional Compatibility Information

Measurement & Control Peripherals

The CR310 is typically not used with measurement and control peripherals because of its limited number of control ports. It is also compatible with low on current and voltage solid-state relays.

The CR310 is not compatible with SDM or CDM devices.

Sensors

With several channel types, the CR310 is compatible with nearly every available sensor. This includes analog output voltage (0 to 2.5 V) and current (0 to 20 mA or 4 to 20 mA) sensors, thermistors, and RTDs to name a few. It is also compatible with pulse or frequency output sensors such as anemometers, rain gauges, and flow meters. CR310 dataloggers are not capable of applying reverse excitation, and they cannot be used with some conductivity or soil matric potential sensors.

SDI-12, Modbus, and other serial sensors are supported with the RS-232 port and C1 and C2 as a Tx/Rx pair. The CR310 does not directly support RS-485 sensors.

Communications

The CR310 can communicate with a PC via its USB port. Compatible telemetry devices include our RS-485 converters, digital cellular gateways, RF telemetry, and satellite transmitters. Data can be viewed on an iOS device, an Android device, or CD295 DataView II Display. To use an iOS or Android device, go to the Apple Store or Google Play and download our free LoggerLink Mobile Apps.

Data Logger Option Communications Type Integrated Communications Are Compatible with

CR310-WIFI

2.4 GHz, 20 MHz bandwidth

Most other Wi-FI devices, such as the CR300-WIFI, CR6-WIFI, NL240

CR310-RF407

902 to 928 MHz Frequency Hopping Spread Spectrum

RF407, CR6-RF407, CRVW3-RF407

CR310-RF412

915 to 928 MHz Frequency Hopping Spread Spectrum

RF412, CR6-RF412, CRVW3-RF412

CR310-RF422

868 MHz SRD860 LBT+AFA

RF422, CR6-RF422, CRVW3-RF422

CR310-CELL

2G Frequency Bands 850, 900, 1800, 1900

3G Frequency Bands 800, 850, 900, 1900, 2100

GSM/GPRS/EDGE (2G)

UMTS/HSPA+ (3G)

Software

The CR300 series is compatible with CRBasic (version 3.6 or higher).

Power

The CR310 uses an external power source and has a built-in charger/regulator. Intelligent power sourcing autoselects the highest voltage from three input sources (Chg, Bat, or USB) to operate in one of the following four modes:

  • UPS (recommended) - A 16 to 32 Vdc source, solar panel (SP10, SP20), or power converter (29796) is used to charge a 12 Vdc battery, such as our BP7 or BP12.
  • 12 Vdc battery or other reliable 12 Vdc source
  • Chg only - DC power supply (16 to 32 Vdc)
  • USB - Powered over 5 Vdc USB port for setup, programming, and testing (will not charge battery or boost USB power to provide 12 Vdc to the switched battery terminal SW12)

Enclosures

An ENC10/12 or ENC12/14 enclosure is adequate for most CR310-based systems.

Videos & Tutorials

Downloads

CR300 Series OS v.11.00 (4.93MB) 21-02-2024

This download is for the CR300 series of dataloggers including all CR300 and CR310 models. Execution of this download places the Operating System file(.obj) on your computer. It also updates the CRBasic Editor compiler and support files.

Why Update? This OS fixes issues related to the TX325/TX326, SDI12Recorder and the addition of MQTT along with other fixes and new features. See the revision history for a complete list. With this OS update, it is recommended that you also update the Device Configuration Utility to the most recent version so that new datalogger features are available in the utility.

Note/Warning: Campbell Scientific always recommends updating operating systems on site if possible. When remote updates are required, it is recommended that you implement the necessary precautions to handle unexpected OS upload complications. All datalogger settings should be retained when updated remotely. If you choose to roll back to a previous operating system, the datalogger settings will be reset to default.

Watch the Video Tutorial: Sending an OS to a Local Datalogger.

View Update History

CR300 Series Wifi OS Update v.1.7.12 (1.97 MB) 13-05-2022

Manufacturer chipset maintenance update.

View Update History

CR300 QuickStart Program (569 KB) 15-03-2016

The CRBasic program referenced in the CR300 QuickStart videos and manual.

Data Logger Wiring Excel Template (1 KB) 26-03-2024

This is a data logger wiring diagram spreadsheet template that accompanies the Wiring Diagram Video. The spreadsheet includes templates for  CR6, CR1000X, CR300, CR310, and CR350 data loggers. The file is an Excel template and works best with Microsoft Excel.

Frequently Asked Questions

Number of FAQs related to CR310: 1

Case Studies

south africa: microclimate analysis
South Africa: Microclimate Analysis
Solar energy is the most abundant clean energy source available on earth, but the intermittent......read more
australia: coastal water-quality monitoring
Australia: Coastal Water-Quality Monitoring
The Port of Townsville Limited (POTL) is undertaking the Channel Upgrade (CU) project at a......read more
panama canal: upgraded flood warning system
Panama Canal: Upgraded Flood Warning System
The Panama Canal was using an outdated water-level system until the Panama Canal Authorities (ACP)......read more
Explore All Case Studies
